Key Technical Specifications

• Output Capacity: 20 kW (20,000 Watts) nominal AC output.
• Battery System: Compatible with 48V Lithium (LFP) or Lead-acid batteries. It features two independent battery inputs.
• Solar Input (PV): Includes 4 MPPTs (Maximum Power Point Trackers), allowing for flexible panel installation across different roof orientations.
• Current Handling: Supports a maximum continuous charging and discharging current of 208A per battery input (totaling up to 416A).
• Efficiency: Maximum efficiency of 97.8%.

Performance Features

• PV Oversizing: Supports up to 200% PV input oversizing (connecting up to 40kW of solar panels) to maximize energy yield.
• Backup Power (UPS): Provides seamless switching to backup mode in less than 4ms, ensuring that critical loads remain powered during grid outages.
• Load Management: Capable of handling 150% unbalanced output, which allows it to power single-phase loads on a three-phase system more flexibly.
• Protection: Built with IP66 dust and water protection for outdoor use, and includes Type II Surge Protection Devices (SPD) on both the DC and AC sides.

Physical Attributes

• Dimensions: Approximately 754 × 549 × 262 mm.
• Cooling: Uses smart fan cooling to manage temperatures during high-power operation.
